Autonomous image – k9w7 (this image is standalone)
full lightweight IOS -k9w8 (this works with controller)
To see the image do show ver with console access
AP#capwap ap ip address <IP address> <subnet mask>
AP#capwap ap ip default-gateway <IP-address>
AP#capwap ap controller ip address 10.96.250.10
AP#capwap ap hostname AP1
AP#lwapp ap ip address 10.96.190.14 255.255.255.224
AP#lwapp ap ip default-gateway 10.96.190.1
AP#capwap ap controller ip address 10.27.90.99
AP#lwapp ap hostname AP2
1.Connect the AP to the switch and assign the AP management Vlan
2. Look for the new AP with show cdp ne to configure the rest on the wireless controller
3. Access Wireless Controller
eg ( https://10.100.14.20/)
4. Configure AP (AP Name…etc).
Click on “Wireless” tab.
Click “Change Filter”
For “Search AP” select the AP ” option box and enter AP name you got on the switch
Once found click the AP Name .
Enter the new AP Name, location in the “General” tab.
Modify “Location” to where the AP will be located.
Click “Apply”
5. WLANS – Add AP to AP Group
Click the WLANs tab.
Click “Advanced”
Click “AP Groups”
Click the AP Group Name that AP will be associated with.
Click “AP’s” tab.
Search for AP in the right hand column.
Click box next to AP and click “Add AP’s”
6. Add AP to AP Policy. ( these will vary from company to company)
Click the “Security” tab
Under “AAA” click the “AP Policies” sub-category.
Click “Add” in the top right corner.
Enter the MAC Address of AP
Click “Apply”
a) Agree on Cawap/Lwap
b) Agree on group name mobility
c) Agree on the same Virtual IP Address
Configuration
Tell them about each other in terms IP, Mac address, Hash( If available) to neighbor up
Click on controller tab
Collapse “Mobility Management”
Click “Mobility Groups”
Click New at far right top and (copy both the IP, Mac,and Hash your neighbor WLC and paste)
show run-config commands
show ap summary
show arp switch
show client summary
Hold reset for over 30 seconds to get to ROMMON
ap:delete flash:private-config
ap:delete flash:private-multiple-fs
ap:boot
Your AP will be factory default
